Elgato Wave XLR | Desktop | XLR, 3.5mm, USB Type-C | 3.2 Gen 1

R3,250.00

Elgato Wave XLR – Technical Specifications

General

  • Product Name: Elgato Wave XLR
  • SKU: 10MAG9901
  • Product Type: Desktop XLR Audio Interface
  • Colour: Black

Audio Interface

  • Input Type: XLR (Balanced)
  • Gain Range: 0dB to 75dB (Ultra-Low-Noise Gain)
  • Phantom Power: +48V DC for condenser microphones
  • Bit Depth: 24-bit
  • Sampling Rate: 48kHz (Supports up to 96kHz)

Connectivity

  • USB Port: USB Type-C (USB 3.2 Gen 1 / USB 3.1 Gen 1 compatible)
  • Headphone Output: 3.5mm stereo jack
  • Headphone Impedance: 16 ohms
  • Headphone Output Power: 30mW per channel @ 32 ohms
  • Latency: Zero-latency direct monitoring
  • Microphone Preamp: High-quality, ultra-low-noise preamp with adjustable gain

Controls and Indicators

  • Control Dial:
    • Multifunctional control dial for adjusting gain, headphone volume, and monitoring mix
    • Press to cycle between gain, headphone volume, and monitor mix adjustment modes
  • Mute Button: Capacitive touch-sensitive mute button for instant mic muting
  • LED Indicators: Multi-color LED ring around the control dial indicating levels and modes

Software Integration

  • Wave Link Software:
    • Supports mixing of up to 9 audio channels
    • Real-time audio processing (EQ, compression, etc.)
    • Customizable audio routing and effects application
  • Clipguard Technology: Automatically reroutes audio to prevent distortion during loud peaks

Power and Requirements

  • Power Supply: Powered via USB (5V, 500mA)
  • System Requirements:
    • Operating System: Windows 10 (64-bit) or later, macOS 10.15 or later
    • Processor: Intel Core i3 or AMD equivalent (minimum)
    • RAM: 4GB (8GB recommended)
    • USB Port: USB 2.0/3.0/3.1/3.2 Compatible

Physical Specifications

  • Dimensions:
    • Width: 70mm (2.76 inches)
    • Height: 70mm (2.76 inches)
    • Depth: 120mm (4.72 inches)
  • Weight: 340g (12 ounces)
  • Material: Metal chassis with a matte black finish

Environmental Requirements

  • Operating Temperature: 0°C to 40°C (32°F to 104°F)
  • Storage Temperature: -20°C to 60°C (-4°F to 140°F)
  • Humidity: 20% to 80% non-condensing

Package Contents

  • Elgato Wave XLR 10MAG9901
  • USB Type-C to USB-A Cable (1.5m)
  • Quick Start Guide
  • Safety Information

Warranty

  • Warranty Period: 2 years (manufacturer warranty)
The Elgato Wave XLR offers a professional-grade solution for streamers and content creators, providing exceptional audio quality and easy integration with your setup. Its robust features and versatile connectivity make it an essential tool for elevating your audio production.
Add to Wishlist
Add to Wishlist
Add to Wishlist
Add to Wishlist

Description

Elgato Wave XLR – Elevate Your Audio Game

Professional Audio Interface for Streamers and Creators

The Elgato Wave XLR is a game-changing audio interface designed to seamlessly bridge the gap between professional XLR microphones and your desktop setup. Ideal for streamers, podcasters, and content creators, this powerful device transforms your audio experience by delivering studio-quality sound with user-friendly controls. With its sleek design and cutting-edge technology, the Wave XLR is an essential tool for anyone serious about their audio.

Unleash the Power of XLR

The Wave XLR allows you to connect your favourite professional XLR microphone directly to your computer via USB Type-C, ensuring that your voice is captured with the highest fidelity. Supporting up to 75dB of ultra-low-noise gain, the Wave XLR ensures that even the most demanding microphones are fully amplified without introducing unwanted noise. This makes it perfect for dynamic microphones, which typically require more gain than condenser microphones.

Intuitive Controls and Customization

Designed with creators in mind, the Wave XLR features a large multifunctional control dial that offers intuitive control over gain, headphone volume, and microphone monitoring. With the capacitive mute button, you can instantly silence your microphone with a simple touch, making it perfect for live broadcasts or recordings where quick reactions are key. The device also integrates seamlessly with Elgato’s Wave Link software, allowing you to mix up to nine audio channels and apply real-time effects for a truly customizable audio experience.

High-Quality Build and Connectivity

Built with a sleek, compact design, the Wave XLR is as aesthetically pleasing as it is functional. Its robust metal chassis ensures durability, while the black finish adds a touch of professionalism to your setup. Connectivity is straightforward with the USB Type-C interface, ensuring fast data transfer and compatibility with modern devices. The 3.5mm headphone output provides zero-latency monitoring, allowing you to hear your voice in real time without delay.

The Elgato Wave XLR is more than just an audio interface—it’s a powerful tool that elevates your content creation, offering unmatched audio quality, intuitive controls, and seamless integration. Whether you’re a seasoned pro or just starting out, the Wave XLR provides the perfect blend of performance and convenience, making it an indispensable addition to your setup.
