ASUS TUF Gaming Radeon RX 7900 XT | 20 GB | GDDR6 | 320 bit | 7680 x 4320

R22,999.95

ASUS TUF Gaming RX 7900 XT O20G Graphics Card – Technical Specifications


General Information

  • Brand: ASUS
  • Series: TUF Gaming
  • Model: RX 7900 XT O20G
  • SKU Number: 90YV0IV1-M0NA00
  • Product Type: Graphics Card
  • GPU Manufacturer: AMD

Graphics Processing Unit (GPU)

  • GPU Model: AMD Radeon RX 7900 XT
  • Architecture: RDNA 3
  • Stream Processors: 5,376
  • Compute Units: 84
  • Ray Accelerators: 84 (Ray Tracing Cores)
  • Base Clock: 1,850 MHz
  • Game Clock: 2,050 MHz
  • Boost Clock: 2,450 MHz

Memory Specifications

  • Memory Size: 20 GB GDDR6
  • Memory Type: GDDR6
  • Memory Interface: 320-bit
  • Memory Bandwidth: 800 GB/s
  • Memory Clock Speed: 20 Gbps effective

Display and Resolution

  • Maximum Resolution: 7680 x 4320 pixels (8K UHD)
  • Multi-Display Support: Up to 4 displays
  • Display Outputs:
    • 1 x HDMI 2.1
    • 3 x DisplayPort 2.1
  • HDMI Features:
    • HDMI 2.1 supports up to 48 Gbps bandwidth, 4K @ 120Hz, 8K @ 60Hz with DSC
  • DisplayPort Features:
    • DisplayPort 2.1 supports 4K @ 240Hz, 8K @ 60Hz with DSC
  • VR Ready: Yes

Cooling and Thermal Design

  • Cooling Technology: Axial-Tech Triple Fan Design
  • Fan Design:
    • Dual ball bearings for increased longevity
    • IP5X dust resistance
    • 0dB technology for silent operation at low loads
  • Heatsink:
    • Extended heatsink design for improved cooling efficiency
    • Copper heat pipes for optimal heat transfer
  • Thermal Design Power (TDP): 315W
  • Smart Fan Control: Yes, with 3D Active Fan technology

Power Specifications

  • Power Connectors: 3 x 8-pin PCIe power connectors
  • Recommended System Power Supply: 750W minimum
  • Power Phase Design: 20+2 Phase VRM design for stable power delivery and overclocking potential

PCI Express and Interface

  • Interface: PCI Express 4.0 x16
  • Bus Interface Bandwidth: Up to 16 GT/s

Dimensions and Physical Design

  • Dimensions:
    • Length: 336 mm
    • Width: 150 mm
    • Height: 62 mm
  • Slot Size: 3.5-slot design
  • Weight: 1.5 kg
  • Form Factor: ATX

Durability and Build Quality

  • Durability Standards:
    • Military-grade capacitors and components
    • Auto-Extreme Technology for precision manufacturing
    • 144-hour validation program for reliability
  • Backplate: Reinforced metal backplate for structural integrity and protection
  • IP Rating: IP5X certified for dust resistance

RGB Lighting and Customization

  • Lighting System: ASUS Aura Sync RGB lighting
  • Customization: Fully customizable RGB lighting with multiple effects (Static, Breathing, Strobing, etc.)
  • Synchronization: Sync with other Aura Sync-compatible components for a cohesive look

Software and Features

  • Software Suite:
    • ASUS GPU Tweak II for overclocking and performance tuning
    • AMD Radeon Software for driver updates and game optimization
  • Supported Technologies:
    • Ray Tracing
    • AMD FidelityFX Super Resolution (FSR)
    • AMD FreeSync Premium Pro
    • AMD Smart Access Memory (SAM)
    • DirectX 12 Ultimate
    • Vulkan API
    • OpenGL 4.6

System Requirements

  • Operating Systems:
    • Windows 10 (64-bit)
    • Windows 11 (64-bit)
  • Minimum System Power Supply: 750W with 3 x 8-pin PCIe power connectors
  • Available PCIe Slot: One available PCI Express 4.0 x16 slot

Package Contents

  • ASUS TUF Gaming RX 7900 XT O20G Graphics Card
  • Quick Installation Guide
  • Driver CD or USB stick (varies by region)
  • 3 x 8-pin to 2 x 8-pin power adapter

This detailed technical specification provides a comprehensive overview of the ASUS TUF Gaming RX 7900 XT O20G, highlighting its advanced features, durable design, and powerful performance, making it an ideal choice for gamers and professionals seeking a top-tier graphics solution.
Add to Wishlist
Add to Wishlist
Add to Wishlist
Add to Wishlist

Description

ASUS TUF Gaming RX 7900 XT O20G Graphics Card

Unmatched Gaming Power and Performance

The ASUS TUF Gaming RX 7900 XT O20G is engineered for gamers and creators seeking exceptional power and performance. Powered by the AMD Radeon RX 7900 XT GPU, this card delivers cutting-edge gaming experiences with its 20 GB of GDDR6 memory and 320-bit memory interface. Whether you’re pushing the limits in AAA titles or handling intensive creative workloads, the RX 7900 XT provides smooth, high-frame-rate gameplay and fast rendering times, making it an ideal choice for high-performance gaming rigs.

Advanced Cooling for Sustained Performance

ASUS’s renowned TUF Gaming series ensures that your GPU stays cool under pressure. The RX 7900 XT O20G features a triple-fan cooling solution, with axial-tech fans designed for maximum airflow and minimal noise. The dual ball bearings in the fans increase their lifespan, while the enlarged heatsink and copper heat pipes efficiently dissipate heat. Additionally, the card is built with military-grade components that enhance durability, ensuring consistent performance even during marathon gaming sessions.

Crystal-clear Visuals and High-Resolution Support

Experience stunning visuals with the RX 7900 XT, capable of supporting a maximum resolution of 7680 x 4320 pixels (8K). With advanced technologies such as ray tracing, AMD FidelityFX, and Variable Rate Shading, this graphics card delivers ultra-realistic lighting, shadows, and reflections. Whether gaming in 4K or exploring virtual worlds, the RX 7900 XT ensures every detail is rendered with precision, making your gaming experience more immersive than ever.

Next-Gen Connectivity and Features

Equipped with PCI Express 4.0, the ASUS TUF Gaming RX 7900 XT offers increased bandwidth for faster data transfer and reduced latency. The card includes a range of display outputs, including HDMI 2.1 and DisplayPort 2.1, allowing for versatile connectivity with modern displays and VR headsets. It also supports multi-monitor setups, making it a great choice for gamers and professionals alike.

Durable Design and Customizable Aesthetics

Built to last, the TUF Gaming RX 7900 XT is constructed with ASUS’s Auto-Extreme Technology, ensuring precision manufacturing and long-term reliability. The reinforced metal backplate adds structural integrity, while the customizable RGB lighting lets you tailor the card’s appearance to match your setup. Compatible with ASUS Aura Sync, the lighting can be synchronized with other Aura-enabled components, creating a cohesive and visually appealing gaming rig.

Future-Proof Your Gaming Setup

With its powerful performance, advanced cooling, and durable construction, the ASUS TUF Gaming RX 7900 XT O20G is built to handle the demands of next-gen gaming. Whether you’re a competitive gamer or a creative professional, this graphics card provides the power and reliability needed to excel in your digital endeavours.
